Waterproof Fire Barrier Curtain For Thatched Roofs

A range of fire barrier products designed to compartmentalise loft spaces and protect thatched roofs. (PRODUCT 123)

RESET OPTIONS >
REF: PRODUCT 123
Category:

Share on:

  • Description
  • APPLICATION INSTRUCTIONS
  • DOWNLOADS
  • ORDER REFERENCES

Product Description

Want create site? Find Free WordPress Themes and plugins.

This product has three distinct advantages: robust fire defence, a waterproof foil covering to protect against rain penetration, and increased thermal insulation properties complying with new UK heat loss regulations. Maximum 50 metres on a roll.



ADVANTAGES

  • Can be made for use around steel columns and cross members; each section will be made separately with the joint placed where outside materials are being fixed to the steelwork. Where each section comes together, there will be an overlap joint to seal
  • There are no fibres when cutting or fixing the barrier
  • Provides robust fire defence and improves thermal insulation of thatched roofs
  • THS60 will also provide additional waterproofing



FIRE TEST PERFORMANCE

Tested to BS476 Part 22 (1987), achieving up to 81 minutes fire protection.

Did you find apk for android? You can find new Free Android Games and apps.

APPLICATION INSTRUCTIONS

Want create site? Find Free WordPress Themes and plugins.

Barrier curtains can be fitted vertically or horizontally. This product can be overlapped by 30mm; Envirograf® IA adhesive (Product 46) must be used to adhere overlapping joints. Product 123 can be used over roofs as a roof fire-curtain or fitted internally under trusses for protection from internal to external in a fire.  STB/91/T can be adhered to the chimney brickwork up to the height of the thatch using Envirograf® IA adhesive (Product 46).

Did you find apk for android? You can find new Free Android Games and apps.

DOWNLOADS

Want create site? Find Free WordPress Themes and plugins.

Please use the links below to download relevant information as PDF documents:



Technical Information

TD123-TH30&TH70-05-2015



Application Instructions

AP123-08-2015



COSHH Data

TD123-TH30&TH70-05-2015

HS123-THS60-05-2015

Did you find apk for android? You can find new Free Android Games and apps.

ORDER REFERENCES

Want create site? Find Free WordPress Themes and plugins.

FIRE BARRIER CURTAINS

REF WIDTH FIRE RATING
TH30/F 1000mm 30 minutes
TH70/F 1000mm 60 minutes
THS60 1300mm 60 minutes



PROTECTION BOARD FOR CHIMNEY AREAS OF THATCH

A lightweight board for protection of thatch around chimneys.  It can be adhered to the chimney brickwork up to the height of the thatch, using Envirograf® Product 46 (IA)

REF SIZE
STB/91/T 6mm thick x 1000mm x 1200mm
